Mondrian Garden Chair
A weatherproof slat-back garden chair, built from solid wood and painted in the primary palette of red, yellow, and blue. Two work days, one pair of hands, four phases.
| A | Slats — back (x7) | 18 × 45 × 600 mm |
| B | Slats — seat (x6) | 18 × 45 × 500 mm |
| C | Armrests (x2) | 18 × 70 × 600 mm |
| D | Front legs (x2) | 45 × 45 × 450 mm |
| E | Back legs (x2) | 45 × 45 × 900 mm |
| F | Supports & rails | 18 × 45 mm stock |
Also: outdoor wood glue, exterior paint (red, yellow, blue, black, white), screws (5 × 60 mm), wood filler, sandpaper (120/180), primer.
- Green wood splits while drying.
- Paint drips ruin finish.
- Seal end grain.
- Thin coats. Dry between.
-
1 Frame the seat
- Cut and assemble the seat rails.
- Check for square.
- Clamp and screw.
Tip: Pre-drill to prevent splits. -
2 Fit the back slats
- Position slats evenly.
- Secure to top and bottom rail.
- Keep equal spacing.
Tip: Use a spacer block. -
3 Assemble arms & legs
- Attach front & back legs.
- Mount armrests level.
- Reinforce with supports.
Tip: Dry fit everything first. -
4 Sand, paint, protect
- Sand all surfaces smooth.
- Prime and paint slats.
- Let cure 2 days.
Tip: Paint thin coats.
Measure twice. Cut once. Think always.
One garden chair, sealed against weather and ready for two seasons of outdoor service before any maintenance.
Use teak or oak instead of softwood for a chair that outlasts the painter.
- All four legs touch the floor at once. Wobble means a leg is long; trim with a flush-cut saw, do not shim.
- Diagonals across the seat frame match within 2 mm.
- Paint is fully dry to the touch and shows no tackiness after 48 hours.
- End-grain is sealed; water beads on the painted edges instead of soaking in.
- Frame racks during glue-up — release clamps, square with a stick across the diagonals, re-clamp before the glue grabs.
- Paint runs in the corners — lighter coats, brush vertically on the slats, horizontally on the rails. Three thin coats beat one thick one.
- Slats split when screwing — pre-drill 80% of the screw diameter; for hardwoods, use a tapered countersink.
- Glue squeezes out and dries on the surface — wipe wet glue with a damp cloth before clamping; once dry, scrape with a chisel held flat.
Why a Mondrian chair?
Piet Mondriaan reduceerde de wereld tot rechte lijnen en drie primaire kleuren. Een tuinstoel in zijn taal is een oefening in dezelfde discipline: lat na lat, hoek na hoek, geen sierwerk, geen krommingen die de geometrie verzachten. Wat overblijft is een meubel dat tegelijk constructie en compositie is.
Over het ontwerp
De stoel is gebouwd uit zes maten lat-stock. De achterleuning telt zeven verticale latten met een opening van 8 mm tussen elke. De armleuningen lopen recht van voorpoot naar achterpoot. De compositie ontstaat in de laatste fase: één rugleuningvak rood, één zitvlak geel, één armleuning blauw — de overige delen blijven zwart of onbehandeld. De keuze welk vlak welke kleur krijgt, is van jou.
Aan het eind
Twee dagen werk en twee dagen drogen later staat de stoel in de tuin. De verf is hard genoeg om regen te keren. De houtnerf onder de zwarte randen is nog te zien als je dichtbij komt. Vanuit de kamer kijk je naar buiten en ziet een sculptuur die functioneert als zitplaats — precies wat Mondriaan voor ogen had toen hij stoelen tekende voor De Stijl.
